Specification
Bluetooth® Version : 5.0
Bluetooth Chipset : Qualcomm® CSR8675

Supported codec : aptX HD, aptX LL, aptX, AAC, SBC
Bluetooth range : 40 meters, 132 feet
Input: Bluetooth, Stereo Analog RCA, Digital optical
Outputs : Stereo Analog RCA, Digital optical
Input power : 5V, 200 mA
Output voltage : 2.1 Volts RMS
Output impedance : 57 Ohms
Digital to Analog Converter (DAC) : PCM5102A
Frequency response : 10Hz-20kHz(+/- 0.5dB)
Signal to noise ratio :  112dB
Total Harmonic distortion : -93dB
PCM support : 384kHz/32bit
Enclosure : Aluminum

Main Features

Transmitter & Receiver 2-in-1

One portable adapter to use as either transmitter or receiver, powered by the latest Bluetooth 5.0, can pair with two headphones/speakers at the same time.

Bluetooth 5.0

Featuring the latest Bluetooth 5.0 (CSR8675) and support for Qualcomm aptX HD, pick up any kind of music for you lossless and wirelessly. Simple switch to alternate between HD and low latency priority If your device supports both codecs.

Audiophile Grade DAC

Features the best in class true Hi-Fi 384kHz/32bit up-sampling audiophile DAC - PCM5102A by TI that sports a high SNR of 112dB and is well regarded for its impressive low noise and low distortion characteristics. In short, this means that the sound you hear is crystal clear, rich and retains a wonderfully full dynamic range.

Optical + RCA

Enables you get maximum flexibility with support for both RCA and optical digital, both input and output are supported.

High Definition Audio

Supports Qualcomm aptX HD which is an enhanced audio codec that allows you to receive 48KHz/24-bit audio via Bluetooth and has been engineered to improve the signal-to-noise ratio, resulting in lower background noise. It preserves sound data through the audio transmission, resulting in a ‘better-than-CD’ listening experience

Dual Link No Delay

Qualcomm aptX Low Latency technology eliminates Bluetooth audio delay, so you can watch TV / Movie / Video in perfect synchronization. Dual link feature of BTR12HD Bluetooth adapter also enables simultaneous streaming to 2 headphones or speakers.
